316 Sanitary Stainless Steel Tubing Tube 309 DIN BA Welded Seamless

Name: 316 Sanitary Stainless Steel Tubing Tube 309 DIN BA Welded Seamless
Brand: Chuanxing
SKU: 201, 202, 301, 302, 303, 304, 304L, 304H, 309, 309S, 310S, 316, 316L, 317L, 321, 409L, 410, 410S, 420, 420J1, 420J2, 430, 444, 441, 904L, 2205, 2507, 2101, 2520, 2304, 254SMO, 253MA, F55
Rating: 4.6 (193 reviews)

Product Details:

Place of Origin:	China
Brand Name:	Chuanxing
Certification:	ASTM,JIS,EN,DIN,GB, JIS
Model Number:	201, 202, 301, 302, 303, 304, 304L, 304H, 309, 309S, 310S, 316, 316L, 317L, 321, 409L, 410, 410S, 420, 420J1, 420J2, 430, 444, 441, 904L, 2205, 2507, 2101, 2520, 2304, 254SMO, 253MA, F55

Payment & Shipping Terms:

Minimum Order Quantity:	1 Ton
Price:	Negotiable
Packaging Details:	Standard Shipping Packing
Delivery Time:	7-15 Days
Payment Terms:	TT, L/C
Supply Ability:	50000 Tons/year

Contact Now

Detailed Product Description

Product Name:	Stainless Steel Pipes	Width:	3mm-2000mm Or As Required
Oiled Or Non-oiled:	Non-oiled	Surface:	BA/ 2B/ NO.1/ NO.3/ NO.4/ 8K/ HL/ 2D/ 1D
Package:	Standard Export Package	Technique:	Hot Rolled, Cold Rolled
Thickness:	0.1mm-300mm Or As Required	Length:	As Required
High Light:	316 Sanitary Stainless Steel Tubing Tube 309 DIN BA Welded Seamless

316 Sanitary Stainless Steel Tubing Tube 309 DIN BA Welded Seamless

Product Description:

Polishing Ss Welded Stainless Steel Pipe Tube High Quality Stainless Steel Welded Pipe seamless pipe

Stainless steel 316/316L Grade :

Alloy 316/316L is molybdenum-bearing austenitic stainless steel. The higher nickel and molybdenum content in this grade allows it to demonstrate better overall corrosion resistant properties than 304, especially with regard to pitting and crevice corrosion in chloride environments. In addition, Alloy 316/ 316L provides excellent elevated temperature tensile, creep and stress-rupture strengths, as well as outstanding formability and weldability. 316L is the lower carbon version of 316 and is immune from sensitization; therefore, it is very frequently used in heavy gauge welded components.

Product Description

Surface finish	Characteristics & Application
NO.1	Hot-rolled surface,annealed and pickled,can be used as cold-rolling material,industial tanks and chem i cal devices.
NO.2D	Cold-rolled, an nealed and pick led with out skinpassing the dull prod ucts can be used as auto mo bile parts, build ing materrials and pipings.
NO.2B	The surface brightness and flatness of NO.2B is better than NO.2D. Then through a special surfacetreament to improve its mechamical properties, N02B could nearly satisfy com pre hen sive uses.
NO.3	Polished with abra sive belt of grit #100#120,have bet ter bright ness with dis con tin u ous coarse stria, used as in ner and ex ter nal or na ments for building, elec tri cal ap pli anc es and kitchen uten sils etc.
NO.4	Polished with abrasive belt of grit #150#180, have better brightness with discontinuous coarse stria, but thinner than NO.3, are used as bathtud buildinginner and external ornaments electrical appliances, kitchen utensils and food processing equipment etc.
HL	Polished with abrasive belt of grit #150-320 on the No.4 finish and has continuous streaks, mainly used as building ornaments, elevators, door of building, frontal plate etc.
BA	Cold rolled, bright an nealed and skin passed, the prod uct has ex cel lent bright ness and good re flex iv i ty like mirror, used for lectrical appliances, mirror, kitch en apparatus, or na ment ma te ri als etc.

316 Sanitary Stainless Steel Tubing Tube 309 DIN BA Welded Seamless 0

Product Details

Product name	201/202/304/304L/316/316L/ 321/309S/310S/410/420/430 Stainless Steel Pipe/Tube
Standard	ASME, ASTM, EN ,BS,GB,DIN, JIS etc
Brand	201/202/304/304L/316/316L/ 321/309S/310S/410/420/430
Certificate	BV, ISO, CE, SGS etc
Type	Seamless & welded
Outter Diameter (OD)	3-1220mm
Thickness	0.5-50mm
Length	6000mm 5800mm 12000mm or Customized
Technique	Cold Drawn or Hot
Surface	2B, No.1, No.4, HL, BA, 8K etc
Application	Stainless steel sheet applies to construction field, ships building industry, petroleum & chemical industries,war and electricity industries, food processing and medical industry, boiler heat exchanger,machinery and hardware fields.
Packing	Standard export sea-worthy packing
Delivery Time	7-15 Working Days after Deposit
TradeTerms	FOB, CFR, CIF, EXW
Payment Terms	30%T/T,L/C

Surface Description

Surface	Definition	Application
No.1	The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling.	Chemical tank, pipe etc.
No.3	Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001.	Kitchen utensils, Building construction etc.
No.4	Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001.	Kitchen utensils, Building construction, Medical equipment etc.
2B	Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster.	Medical equipment, Food industry, Construction material, Kitchen utensils etc.
BA (No.6)	Those processed with bright heat treatment after cold rolling.	Kitchen utensils, Electric equipment, Building construction etc.
Mirror (No.8)	Shinning like a mirror	Building construction, decoration etc.
Hairline	Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size.	Building Construction etc.

Application

316 Sanitary Stainless Steel Tubing Tube 309 DIN BA Welded Seamless 1

Chemical Composition

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0 .15	≤0 .75	5. 5-7. 5	≤0.06	≤ 0.03	3.5 -5.5	16 .0 -18.0	-
202	≤0 .15	≤l.0	7.5-10.0	≤0.06	≤ 0.03	4.0-6.0	17.0-19.0	-
301	≤0 .15	≤l.0	≤2.0	≤0.045	≤ 0.03	6.0-8.0	16.0-18.0	-
302	≤0 .15	≤1.0	≤2.0	≤0.035	≤ 0.03	8.0-10.0	17.0-19.0	-
304	≤0 .0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	8.0-10.5	18.0-20.0	-
304L	≤0.03	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0-13.0	18.0-20.0	-
309S	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0-15.0	22.0-24.0	-
310S	≤0.08	≤1.5	≤2.0	≤0.035	≤ 0.03	19.0-22.0	24.0-26.0
316	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	10.0-14.0	16.0-18.0	2.0-
316L	≤0 .03	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0 - 15.0	16 .0 -1 8.0	2.0 -
321	≤ 0 .08	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0 - 13 .0	17.0 -1 9.0	-
630	≤ 0 .07	≤1.0	≤1.0	≤0.035	≤ 0.03	3.0-5.0	15.5-17.5	-
631	≤0.09	≤1.0	≤1.0	≤0.030	≤0.035	6.50-7.75	16.0-18.0	-
904L	≤ 2 .0	≤0.045	≤1.0	≤0.035	-	23.0·28.0	19.0-23.0	4.0-5.0
2205	≤0.03	≤1.0	≤2.0	≤0.030	≤0.02	4.5-6.5	22.0-23.0	3.0-3.5
2507	≤0.03	≤0.8	≤1.2	≤0.035	≤0.02	6.0-8.0	24.0-26.0	3.0-5.0
2520	≤0.08	≤1.5	≤2.0	≤0.045	≤ 0.03	0.19 -0. 22	0. 24 -0 . 26	-
410	≤0.15	≤1.0	≤1.0	≤0.035	≤ 0.03	-	11.5-13.5	-
430	≤0.1 2	≤0.75	≤1.0	≤ 0.040	≤ 0.03	≤0.60	16.0 -18.0	-
